TracoPower TEL 12-2422 DC/DC converter 0.5 A 12 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 27.72
30
4% = € 1.21
€ 26.51
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 27.72 / piece)
€
Highlights & Details
DC DC Converters
- Output /0.5 A;Power 12 W;Solder pins
Technical specifications
- Max. output current
0.5 A
- Output current (max.) - rounded
500 mA
- Dim
(L x W x H) 23.8 x 13.7 x 14.0 mm
- Height
14.0 mm
- Length
23.8 mm
- Width
13.7 mm
- Connection
Solder pins
- Type
closed
- Type
TEL 12-2422
- Input voltage (max.)
36.0 V DC
- Min. input voltage
18.0 V DC
- Operating temperature (max.)
88 °C
- Operating temperature (min.)
-40 °C
- No. of outputs
2 x
12 W
- Weight
8.6 g
- Product type
DC/DC converter
Documents & Downloads
Datasheet
Datasheet 3372611 TracoPower TEL 12-2422 DC/DC converter 0.5 A 12 W
Datasheet 3372611 TracoPower TEL 12-2422 DC/DC converter 0.5 A 12 W
User & Safety Instructions
User & Safety Instructions 3372611 TracoPower TEL 12-2422 DC/DC converter 0.5 A 12 W
Warranty Terms
Warranty Terms 3372611 TracoPower TEL 12-2422 DC/DC converter 0.5 A 12 W
