TracoPower TEL 3-2423 DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 16.80
3
5% = € 0.83
€ 15.97
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 16.80 / piece)
€
Highlights & Details
DC/DC converter TEL 3 series, 3 W, DIL-24
- Protected against permanent short circuit
- 3 year guarantee
Technical specifications
- Ripple: (20 MHz bandwidth) 60 mVpp
- Power control ± 0.5%
- Load regulation (%): (Single) ±0.5%/(Dual) ± 1%
- Type
TEL 3-2423
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
100 mA
- Output current (max.) - rounded
100 mA
- Efficiency (max.)
78 %
3 W
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-25 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 32 x 20 x 10 mm
- Height
10 mm
- Length
32 mm
- Width
20 mm
- Content
1 pc(s)
3 W
- Output voltage
±15 V DC
- Output current (details)
±100 mA
- Type
TEL 3 Series
- Operating temperature
-25 - +75 °C
- Mains control
max. ±0.5 %
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 154554 TracoPower TEL 3-2423 DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 154554 TracoPower TEL 3-2423 DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154554 TracoPower TEL 3-2423 DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Description
Wide 2:1input range, EN/IEC 60950, UL/cUL 1950.
Features
- Further 2:1 input range
- Permanent short circuit.
