TracoPower TEL 8-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 24.36
30
4% = € 1.06
€ 23.30
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 24.36 / piece)
€
Technical specifications
- Type
TEL 8-2422
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
335 mA
- Output current (max.) - rounded
335 mA
- Efficiency (max.)
85 %
8 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 16
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 24.1 x 12.3 x 14 mm
- Height
14 mm
- Length
24.1 mm
- Width
12.3 mm
- Content
1 pc(s)
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
6.1 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3372833 TracoPower TEL 8-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372833 TracoPower TEL 8-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372833 TracoPower TEL 8-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Description
DC/DC converter TEL 8 series
Ultra-compact 8W converter in the DIL-16 metal housing, 2:1 input range, input filter according to EN 55022, class A, short-circuit proof.
This text is machine translated.
Ultra-compact 8W converter in the DIL-16 metal housing, 2:1 input range, input filter according to EN 55022, class A, short-circuit proof.
