TracoPower TEN 3-4811WIN DC/DC converter (print) 48 V DC 5 V DC 500 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 16.80
30
5% = € 0.83
€ 15.97
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 16.80 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 3-4811WIN
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
80 %
3 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.8 x 14.7 x 20.3 mm
- Height
20.3 mm
- Length
31.8 mm
- Width
14.7 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
12.8 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370477 TracoPower TEN 3-4811WIN DC/DC converter (print) 48 V DC 5 V DC 500 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370477 TracoPower TEN 3-4811WIN DC/DC converter (print) 48 V DC 5 V DC 500 mA 3 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370477 TracoPower TEN 3-4811WIN DC/DC converter (print) 48 V DC 5 V DC 500 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370477 TracoPower TEN 3-4811WIN DC/DC converter (print) 48 V DC 5 V DC 500 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, protected against permanent short circuit, I/O insulation 1500 V/DC, input filter EN 55022, class A, Industry-standard pinning, cost-optimized new design.
This text is machine translated.
This text is machine translated.
