TracoPower TEN 30-2411WI DC/DC converter (print) 24 V DC 5.1 V DC 6 A 30 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 80.66 / piece)
€
Highlights & Details
DC/DC converter TEN 30-Series
- Wide 4:1 input voltage range
Technical specifications
- Control deviations: For input variation max. ± 0.5 %, for load variation max. ±3 %
- Product type
DC/DC converter (print)
- Type
TEN 30-2411WI
- Nominal voltage
24 V DC
- Min. input voltage
10 V DC
- Input voltage (max.)
40 V DC
- No. of outputs
1 x
- Output voltages
5.1 V DC
- Max. output current
6 A
- Output current (max.) - rounded
6 A
- Efficiency (max.)
87 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 40.6 x 10.2 mm
- Height
10.2 mm
- Length
50.8 mm
- Width
40.6 mm
- Content
1 pc(s)
30 W
- Type
TEN 30 Series
- Operating temperature
(above 60 ºC power reduction 2 %/K) -40 - +85 ºC
