TracoPower TEN 6-2413WIN DC/DC converter (print) 24 V DC 15 V DC 400 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 22.68
30
4% = € 0.98
€ 21.70
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 22.68 / piece)
€
Highlights & Details
DC/DC converter TEN 6-Series
- Ultra wide 4:1 input ranges
- High efficiency
- Operating temperature range -40°C to +85°C.
- No base load required
- E/A-INSULATION 1500 VDC
- Input filter in accordance with EN 55022, class A
- Overload protection
- DIL-24 plastic casing
- Industry-standard pinning
Technical specifications
- Control deviations: Input change: 0.5 % , load change (0-100%): 1.2 %
- Remaining ripple <80 mV pk-pk (20 MHz bandwidth)
- Short circuit protection: Continuous
- Safety standards UL/cUL 60950-1, IEC/EN 60950-1.
- Type
TEN 6-2413WIN
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
400 mA
- Output current (max.) - rounded
400 mA
- Efficiency (max.)
84 %
6 W
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.80 x 20.30 x 10.20 mm
- Height
10.20 mm
- Length
31.80 mm
- Width
20.30 mm
- Content
1 pc(s)
- Weight
4.8 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3370046 TracoPower TEN 6-2413WIN DC/DC converter (print) 24 V DC 15 V DC 400 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370046 TracoPower TEN 6-2413WIN DC/DC converter (print) 24 V DC 15 V DC 400 mA 6 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370046 TracoPower TEN 6-2413WIN DC/DC converter (print) 24 V DC 15 V DC 400 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370046 TracoPower TEN 6-2413WIN DC/DC converter (print) 24 V DC 15 V DC 400 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Description
The TEN-6WIN series offers an excellent price/performance ratio at a
Output power of 6 W. The general properties, such as those that are not required
Minimum load, overload protection, an integrated filter according to EN 55022 class
A as well as a high degree of efficiency permit a simple design-in. The advanced
Wide, common DIL-24 standard casings enable a simple
Replacement of other converters in many cost-critical applications.
This text is machine translated.
Output power of 6 W. The general properties, such as those that are not required
Minimum load, overload protection, an integrated filter according to EN 55022 class
A as well as a high degree of efficiency permit a simple design-in. The advanced
Wide, common DIL-24 standard casings enable a simple
Replacement of other converters in many cost-critical applications.
This text is machine translated.
