TracoPower TEN 6-2421N DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 500 mA 6 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 23.52
30
4% = € 1.02
€ 22.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 23.52 / piece)
€
Technical specifications
- Type
TEN 6-2421N
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
-5 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
80 %
6 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.8 x 14.3 x 20.3 mm
- Height
20.3 mm
- Length
31.8 mm
- Width
14.3 mm
- Content
1 pc(s)
- Output voltage (max.)
5 V DC
-5 V DC
- Output voltage (min.)
5 V DC
-5 V DC
- Weight
13 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3370688 TracoPower TEN 6-2421N DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 500 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3370688 TracoPower TEN 6-2421N DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 500 mA 6 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370688 TracoPower TEN 6-2421N DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 500 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370688 TracoPower TEN 6-2421N DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 500 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Description
2:1 input range, input filter according to EN 55022, class A, short-circuit proof, E/A-insulation 1500 V/DC, DIL 24 casing with industry-standard pins, cost-optimized new design.
