TracoPower TEN 60-2422WIR DC/DC converter (print) 2.5 A 60 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 121.84 / piece)
€
Technical specifications
- Type
TEN 60-2422WIR
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
2.5 A
- Output current (max.) - rounded
2.5 A
- Efficiency (max.)
91 %
60 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 40.7 x 25.4 mm
- Height
25.4 mm
- Length
50.8 mm
- Width
40.7 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
66.9 g
- Product type
DC/DC converter (print)
