TracoPower TEN 8-4813WI DC/DC converter (print) 48 V DC 15 V DC 533 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 37.81 / piece)
€
Highlights & Details
TracoPower TEN 8-4813WI DC/DC converter (print) 48 V DC 15 V DC 533 mA 8 W No. of outputs: 1 x Content 1 pc(s)
- Ultra wide 4:1 input ranges
- DIL-24 Metal housing
- Approval according to EN 50155 for railway applications
- Thermal shock and vibration according to EN 61373
- High efficiency
- No base load required
- Operating temperature range --40°C to +85°C.
- Remote on/off
- Undervoltage switch-off at the input
- Shielded metal casing with insulated base plate
Technical specifications
- Control deviations: For input variation max. ± 2 %, for load variation max. ±0.5 % (single output)/max. ±1 % (dual output)
- Ripple: 50 mV pk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TEN 8-4813WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
533 mA
- Output current (max.) - rounded
533 mA
- Efficiency (max.)
88 %
8 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 32.00 x 20.30 x 10.20 mm
- Height
10.20 mm
- Length
32.00 mm
- Width
20.30 mm
- Weight
18 g
- Content
1 pc(s)
8 W
- Type
TEN 8 Series
- Operating temperature
(above 70 ºC power reduction 3.5 %/K) -40 - +85 ºC °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 3370051 TracoPower TEN 8-4813WI DC/DC converter (print) 48 V DC 15 V DC 533 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370051 TracoPower TEN 8-4813WI DC/DC converter (print) 48 V DC 15 V DC 533 mA 8 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370051 TracoPower TEN 8-4813WI DC/DC converter (print) 48 V DC 15 V DC 533 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370051 TracoPower TEN 8-4813WI DC/DC converter (print) 48 V DC 15 V DC 533 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Description
Ultra wide 4:1 input range, high degree of efficiency, input filter according to EN55022, class A and FCC, level A (with external condenser). Continuous short circuit protection, six-sided shielded metal housing with insulated base plate, external on/off, industry standard footprint. Safety/approvals standards: cUL/UL 60950-1, IEC/EN 60950-1.
