TracoPower THB 6-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 57.13 / piece)
€
Technical specifications
- Type
THB 6-1223
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
78 %
6 W
- Insulation voltage
3000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
71 °C
- Dim
(L x W x H) 31.8 x 20.3 x 15.8 mm
- Height
15.8 mm
- Length
31.8 mm
- Width
20.3 mm
- Content
1 pc(s)
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
18 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3370750 TracoPower THB 6-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3370750 TracoPower THB 6-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370750 TracoPower THB 6-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370750 TracoPower THB 6-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Description
E/A-insulation 3000 VAC designed for 1000 V/AC operating voltage. Approval according to medical standard UL 60601-1 and IEC/EN 60601-1, 3rd edition, 2 x MOOP. 2:1 input range, low leakage current, short-circuit proof.
