TracoPower THD 10-2415WIN DC/DC converter (print) 24 V DC 15 V DC 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 31.92
30
4% = € 1.38
€ 30.54
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 31.92 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THD 10-2415WIN
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
666 mA
- Output current (max.) - rounded
666 mA
- Efficiency (max.)
89 %
10 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.8 x 20.3 x 14.3 mm
- Height
14.3 mm
- Length
31.8 mm
- Width
20.3 mm
- Output voltage (max.)
15 V DC
- Output voltage (min.)
15 V DC
- Weight
17.3 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370770 TracoPower THD 10-2415WIN DC/DC converter (print) 24 V DC 15 V DC 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370770 TracoPower THD 10-2415WIN DC/DC converter (print) 24 V DC 15 V DC 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370770 TracoPower THD 10-2415WIN DC/DC converter (print) 24 V DC 15 V DC 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370770 TracoPower THD 10-2415WIN DC/DC converter (print) 24 V DC 15 V DC 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, short-circuit proof, E/A-insulation 1500 V/DC, input filter according to EN 55022, class A, industry-standard pinning, cost-optimized new design.
