TracoPower THL 10-4823WI DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 36.97 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THL 10-4823WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
333 mA
- Output current (max.) - rounded
333 mA
- Efficiency (max.)
87 %
10 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
15 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370895 TracoPower THL 10-4823WI DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(
Datasheet 3370895 TracoPower THL 10-4823WI DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(
User & Safety Instructions
User & Safety Instructions 3370895 TracoPower THL 10-4823WI DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(
Warranty Terms
Warranty Terms 3370895 TracoPower THL 10-4823WI DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(
Description
10 Watt in 25.4 mm x 25.4 mm metal housing, 4:1 input range, input/output insulation 1500 V/DC, input filter according to EN 55022, class A.
