TracoPower THM 10-4821 DC/DC converter (print) 5 V DC 1 A 10 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 55.45 / piece)
€
Technical specifications
- Type
THM 10-4821
- Min. input voltage
7 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Efficiency (max.)
85 %
10 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 31.80 x 20.30 x 10.20 mm
- Height
10.20 mm
- Length
31.80 mm
- Width
20.30 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
5.0 V DC
-5.0 V DC
- Output voltage (min.)
5.0 V DC
-5.0 V DC
- Weight
14 g
- Product type
DC/DC converter (print)
