TracoPower THM 30-4811WI DC/DC converter (print) 48 V DC 6 A 30 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 109.24 / piece)
€
Technical specifications
- Type
THM 30-4811WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Max. output current
6 A
- Output current (max.) - rounded
6 A
- Efficiency (max.)
89 %
30 W
- Insulation voltage
5000 V AC
- Enclosure
DIP 10 (1/8 brick)
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+80 °C
- Dim
(L x W x H) 50.8 x 25.4 x 15.8 mm
- Height
15.8 mm
- Length
50.8 mm
- Width
25.4 mm
- Content
1 pc(s)
- Output voltage (max.)
5 V DC
- Product type
DC/DC converter (print)
