TracoPower THM 6-4823 DC/DC converter (print) 3.3 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 48.73 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THM 6-4823
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
3.3 V DC
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
87 %
6 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 31.80 x 20.30 x 10.20 mm
- Height
10.20 mm
- Length
31.80 mm
- Width
20.30 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
14 g
- Content
1 pc(s)
