TracoPower THN 10-4813WIR DC/DC converter (print) 670 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 37.81 / piece)
€
Technical specifications
- Type
THN 10-4813WIR
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Max. output current
670 mA
- Output current (max.) - rounded
670 mA
- Efficiency (max.)
90 %
10 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 25.4 x 25.4 x 9.9 mm
- Height
9.9 mm
- Length
25.4 mm
- Width
25.4 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
16.5 g
- Product type
DC/DC converter (print)
