TracoPower THN 15-7215WIR DC/DC converter (print) 72 V DC +24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 57.13 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 15-7215WIR
- Nominal voltage
72 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
1 x
- Output voltages
+24 V DC
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
- Efficiency (max.)
90 %
15 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 25.4 x 25.4 x 15.5 mm
- Height
15.5 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Output current (min.)
0 mA
- Weight
16.5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371600 TracoPower THN 15-7215WIR DC/DC converter (print) 72 V DC +24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371600 TracoPower THN 15-7215WIR DC/DC converter (print) 72 V DC +24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371600 TracoPower THN 15-7215WIR DC/DC converter (print) 72 V DC +24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371600 TracoPower THN 15-7215WIR DC/DC converter (print) 72 V DC +24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, according to EN 50155 and EN 61373 approvals for railways. Permanent short circuit and low-voltage cut-off, remote on/off. Output voltage can be set Input filter to EN 55011, class A.
