TracoPower THN 20-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 52.09 / piece)
€ 520.90
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 20-2422
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
833 mA
- Output current (max.) - rounded
833 mA
- Efficiency (max.)
90 %
20 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
15 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371061 TracoPower THN 20-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3371061 TracoPower THN 20-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371061 TracoPower THN 20-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371061 TracoPower THN 20-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
Description
Ultra-compact dimensions: 25.4 mm x 25.4 mm x 10.2 mm, 2:1 input range, input/output insulation 1500 V/DC, external on/off, input filter according to EN 55022, class A.
