TracoPower THN 30-1215 DC/DC converter (print) 12 V DC 24 V DC 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 72.26 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 30-1215
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Output voltages
24 V DC
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Efficiency (max.)
89 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Weight
16.5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371081 TracoPower THN 30-1215 DC/DC converter (print) 12 V DC 24 V DC 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371081 TracoPower THN 30-1215 DC/DC converter (print) 12 V DC 24 V DC 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371081 TracoPower THN 30-1215 DC/DC converter (print) 12 V DC 24 V DC 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371081 TracoPower THN 30-1215 DC/DC converter (print) 12 V DC 24 V DC 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
Description
Ultra-compact dimensions: 25.4 mm x 25.4 mm x 10.2 mm, 2:1 input range, input/output insulation 1500 V/DC, external on/off, input filter according to EN 55022, class A.
