TracoPower THN 30-7225WIR DC/DC converter (print) 24 V DC 9 V DC 625 mA 30 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 73.94 / piece)
€
Technical specifications
- Type
THN 30-7225WIR
- Nominal voltage
24 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
2 x
- Output voltages
9 V DC
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
30 W
- Connection
Soldering
- Dim
(L x W x H) 25.40 x 25.40 x 9.90 mm
- Height
9.90 mm
- Length
25.40 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Weight
18
- Product type
DC/DC converter (print)
