TracoPower THR 20-4822WI DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 52.09 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THR 20-4822WI
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
-5 V DC
- Max. output current
833 mA
- Output current (max.) - rounded
833 mA
20 W
- Connection
Soldering
- Dim
(L x W x H) 50.80 x 25.40 x 11 mm
- Height
11 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Weight
40.50
- Content
1 pc(s)
