TracoPower TIM 2-2423 DC/DC converter (print) 67 mA 2 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 31.92
30
4% = € 1.38
€ 30.54
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 31.92 / piece)
€
Technical specifications
- Type
TIM 2-2423
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
67 mA
- Output current (max.) - rounded
67 mA
- Efficiency (max.)
81 %
2 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
95 °C
- Dim
(L x W x H) 24.30 x 14.40 x 10.20 mm
- Height
10.20 mm
- Length
24.30 mm
- Width
14.40 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
7 g
- Product type
DC/DC converter (print)
