Buy TracoPower TMA 1212S DC/DC converter (print) 12 V DC 12 V DC 80 mA 1 W No. of outputs: 1 x Content 1 pc(s)

TracoPower TMA 1212S DC/DC converter (print) 12 V DC 12 V DC 80 mA 1 W No. of outputs: 1 x Content 1 pc(s)-0

Datasheet (PDF)

37 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 5.03 / piece)

€

Report legal concerns

Highlights & Details

DC/DC converter TMA series, 1 W, SIL-7

3 year guarantee
100 % burn-in (8 hours)

Technical specifications

Ripple: (20 MHz bandwidth) 75 mVpp
Load regulation (%): ±10%

Type: TMA 1212S

Nominal voltage: 12 V DC

No. of outputs: 1 x

Output voltages: 12 V DC

Max. output current: 80 mA

Output current (max.) - rounded: 80 mA

Efficiency (max.): 80 %

: 1 W

Enclosure: SIL 7

Connection: Solder pins

Operating temperature (min.): -40 °C

Operating temperature (max.): 85 °C

Dim: (L x W x H) 19.5 x 7 x 10.2 mm

Height: 10.2 mm

Length: 19.5 mm

Width: 7 mm

Content: 1 pc(s)

: 1 W

Output voltage: 12 V DC

Output current (details): 80 mA

Type: TMA Series

Operating temperature: -40 - +85 °C

Mains control: (at 1 % variation Vin) max. ±1.2 %

Product type: DC/DC converter (print)
