TracoPower TMA 1505S DC/DC converter (print) 15 V DC 15 V DC 65 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Total (€ 4.03 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMA 1505S
- Nominal voltage
15 V DC
- Min. input voltage
13.5 V DC
- Input voltage (max.)
16.5 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
65 mA
- Output current (max.) - rounded
65 mA
- Efficiency (max.)
73 %
1 W
- Insulation voltage
1000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 13.4 x 7.1 mm
- Height
7.1 mm
- Length
19.5 mm
- Width
13.4 mm
- Output voltage (max.)
15 V DC
- Output voltage (min.)
15 V DC
- Weight
2.6 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372900 TracoPower TMA 1505S DC/DC converter (print) 15 V DC 15 V DC 65 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372900 TracoPower TMA 1505S DC/DC converter (print) 15 V DC 15 V DC 65 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372900 TracoPower TMA 1505S DC/DC converter (print) 15 V DC 15 V DC 65 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
SIL-7 housing, unregulated output, input/output insulation 1000 V/DC, industry standard footprint.
