TracoPower TMAP 0505S DC/DC converter (print) 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 10.08
30
6% = € 0.58
€ 9.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 10.08 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMAP 0505S
- Min. input voltage
4.5 V DC
- Input voltage (max.)
5.50 V DC
- No. of outputs
1 x
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
78 %
1 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.50 x 7.10 x 10.20 mm
- Height
10.20 mm
- Length
19.50 mm
- Width
7.10 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5.0 V DC
- Output voltage (min.)
5.0 V DC
- Weight
3.10 g
- Content
1 pc(s)
