TracoPower TMDC 10-2418 DC/DC converter 208 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 53.77 / piece)
€
Technical specifications
- Product type
DC/DC converter
- Type
TMDC 10-2418
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
208 mA
- Output current (max.) - rounded
208 mA
- Efficiency (max.)
84 %
10 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 79 x 34 x 22 mm
- Height
22 mm
- Length
79 mm
- Width
34 mm
- RoHS-compliant
Yes
- Output voltage (max.)
48.0 V DC
- Output voltage (min.)
48.0 V DC
- Weight
65.80 g
- Content
1 pc(s)
