TracoPower TMDC 40-7225H DC/DC converter 830 mA 40 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 92.43 / piece)
€
Technical specifications
- Type
TMDC 40-7225H
- Min. input voltage
80 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
2 x
- Max. output current
830 mA
- Output current (max.) - rounded
830 mA
- Efficiency (max.)
87 %
40 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 112.0 x 63.8 x 25.6 mm
- Height
25.6 mm
- Length
112.0 mm
- Width
63.8 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
24 V DC
-24 V DC
- Output voltage (min.)
24 V DC
-24 V DC
- Weight
162 g
- Product type
DC/DC converter
