TracoPower TMV 12159HI DC/DC converter (print) 12 V DC +15 V DC, -9 V DC 33 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 11.76
30
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 11.76 / piece)
€
Technical specifications
- Output current (max.): +33 mA;-55 mA
- Product type
DC/DC converter (print)
- Type
TMV 12159HI
- Nominal voltage
12 V DC
- Min. input voltage
11.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
1 x
- Output voltages
+15 V DC
-9 V DC
- Max. output current
33 mA
- Output current (max.) - rounded
33 mA
- Efficiency (max.)
81 %
1 W
- Insulation voltage
5200 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 13.4 x 7.1 mm
- Height
7.1 mm
- Length
19.5 mm
- Width
13.4 mm
- Output voltage (max.)
15 V DC
-9 V DC
- Output voltage (min.)
15 V DC
-9 V DC
- Weight
2.4 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371363 TracoPower TMV 12159HI DC/DC converter (print) 12 V DC +15 V DC, -9 V DC 33 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371363 TracoPower TMV 12159HI DC/DC converter (print) 12 V DC +15 V DC, -9 V DC 33 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371363 TracoPower TMV 12159HI DC/DC converter (print) 12 V DC +15 V DC, -9 V DC 33 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371363 TracoPower TMV 12159HI DC/DC converter (print) 12 V DC +15 V DC, -9 V DC 33 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact SIL7-casing, E/A-insulation 5200 V/DC, suitable for IGBT applications, unregulated output.
