TracoPower TON 15-4812 DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 47.05 / piece)
€
Technical specifications
- Type
TON 15-4812
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Efficiency (max.)
87 %
15 W
- Insulation voltage
2250 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 23.88 x 27.94 x 13.7 mm
- Height
13.7 mm
- Length
23.88 mm
- Width
27.94 mm
- Content
1 pc(s)
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
10.5 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3371441 TracoPower TON 15-4812 DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371441 TracoPower TON 15-4812 DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371441 TracoPower TON 15-4812 DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371441 TracoPower TON 15-4812 DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact 15 W converter with 2:1 input, open frame construction with industry standard pins, design in through-hole technology, I/O insulation 2250 V/DC, external on/off.
