TracoPower TRI 10-1213 DC/DC converter (print) 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 60.50 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRI 10-1213
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Max. output current
666 mA
- Output current (max.) - rounded
666 mA
- Efficiency (max.)
88 %
10 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.80 x 20.30 x 12 mm
- Height
12 mm
- Length
31.80 mm
- Width
20.30 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
16 g
- Content
1 pc(s)
