TracoPower TVN 3-1221 DC/DC converter (print) 12 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 38.65 / piece)
€
Technical specifications
- Type
TVN 3-1221
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Max. output current
300 mA
- Output current (max.) - rounded
300 mA
- Efficiency (max.)
82 %
3 W
- Insulation voltage
1600 V DC
- Enclosure
SIL 8
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+90 °C
- Dim
(L x W x H) 9.6 x 21.8 x 15.3 mm
- Height
15.3 mm
- Length
9.6 mm
- Width
21.8 mm
- Content
1 pc(s)
- Output voltage (max.)
5.0 V DC
-5.0 V DC
- Weight
5.9 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3371893 TracoPower TVN 3-1221 DC/DC converter (print) 12 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3371893 TracoPower TVN 3-1221 DC/DC converter (print) 12 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371893 TracoPower TVN 3-1221 DC/DC converter (print) 12 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371893 TracoPower TVN 3-1221 DC/DC converter (print) 12 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Description
2:1 input range, compact SIL-8 metal housing. Low ripple of 10 mVpp type. Regulated output, input/output insulation 1600 V/DC. Short-circuit protection, input filter according to EN 55032, class B with ext. Components.
