TRU COMPONENTS Pre-fab braid Total number of pins 2 Contact spacing: 2 mm 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 3
Total (€ 1.25 / piece)
€
Highlights & Details
Connector socket with lead
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 2
Technical specifications
- Cable length 50 cm, free end bared and tin-plated 3mm)
- Connector type
Socket, straight
- Connector system
wire-to-board
- CS
2 mm
- Pins per row
2
- Total number of pins
2
- Nominal current - rounded value
- Content
1 pc(s)
- Dim
- Factory colour
Red
Black
- Length
500 mm
- Compatible with (details)
26
- Industrial packaging
No
- Connection
Open end cable
- Connector contact surface
Tin plated
- Manufacturer part #
546821
- Type
546821
- Nominal voltage
45 V AC
- AWG max.
26
- AWG (min.)
26
- Insulation material
PVC
- No. of rows
1
- Cross section
0.14 mm²
26
- Contact material
Copper alloy
- Case material
PBT
- RoHS-compliant
Yes
- Max. temperature
80 °C
- Product type
Pre-fab braid
Documents & Downloads
Datasheet
Datasheet 546821 TRU COMPONENTS Pre-fab braid Total number of pins 2 Contact spacing: 2 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 546821 TRU COMPONENTS Pre-fab braid Total number of pins 2 Contact spacing: 2 mm 1 pc(s)
Description
Specially suitable for linking pcb connection points to the front panel, for example switches, indicator lamps, leds etc.
