Buy Wieland Electric 96.232.10B4.1 Cable Black

Black cable with three stripped cores in blue, green-yellow, and brown, secured to an electronic terminal block.

Sales and shipping:

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 13.44 / piece)

€

Report legal concerns

Technical specifications

Type A: Open cable ends

Type B: Plug

Factory colour: Black

Cable Ø range: 7.8 - 8.2 mm

: IP66

Number of pins: 3

Test current: 20 A

Rated voltage: 250 V

Cable Ø (max.): 8.2 mm

Cable Ø up to: 7.8 mm

: TRUE

: 1.5 mm²

: H05Z1Z1-F

: Black

: Integrated in plug-in connector

: 20 A

: 250 V

: 1000 mm

: 3

: Black

: 7.8-8.2 mm

: Silver-plated

: 3

: 4 kV

: 11.95 mOhm

: IP66

: L, N, PE

: Black

: 0.4 kWh

: 9 mm

: 35 mm

: Device connection cable

: Free conductor end

: Plug

: 100 °C

: Ultrasonic compressed wire ends

: 70 °C

: B2ca

: s1

: d1

: a1

: 9005

Product type: Cable

Description

RST® CLASSIC connection cable
Free cable end - connector
Number of poles: 3
Rated voltage: 250 V
Rated current 20 A
Cable type H05Z1Z1-F
Fire class B2ca s1 d1
Total length 1 m
Conductor nominal cross-section 1.5 mm²
Coding color / contact insert black
