Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M20
Type
Explosion-proof
Clamp Ø
6 mm
Terminal Ø (max.)
13 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 6.71
5
6% = € 0.41
€ 6.30
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 6.71 / piece)
€
Highlights & Details
Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
- Explosion-proof to II 2 G Ex e II
Technical specifications
- Product type
Cable gland
- Features
ATEX
- Factory colour
Black (RAL 9005)
- External thread
M20
- Type
Explosion-proof
- Clamp Ø
6 mm
- Terminal Ø (max.)
13 mm
- Thread length
15 mm
- Min. temperature
-40 °C
- Max. temperature
+75 °C
IP68
- Spanner size
24 mm
- Halogen-free
No
- Content
1 pc(s)
- Dim
- RoHS-compliant
Yes
- Manufacturer part #
10103381
- Type
ESKE/1-L-e 20
- Material (details)
Polyamide
- Type
ESKE-L-e 20
- Clamping range diameter mm
6 - 13 mm
- Temperature range
-40 - +75 °C
- Size
M20
Variants(All information is without VAT, plus shipping costs)
Clamp Ø
Terminal Ø (max.)
External thread
Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
This article
6 mm
13 mm
M20
Minimum order quantity: 1
Multiple: 1
€ 6.71*
Wiska 10103364 Cable gland ATEX M16 Black (RAL 9005) 1 pc(s)
4 mm
9 mm
M16
Minimum order quantity: 1
Multiple: 1
€ 2.34*
Wiska 10103365 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
6 mm
13 mm
M20
Minimum order quantity: 1
Multiple: 1
€ 2.76*
Wiska 10103366 Cable gland ATEX M25 Black (RAL 9005) 1 pc(s)
10 mm
17 mm
M25
Minimum order quantity: 1
Multiple: 1
€ 6.29*
Wiska 10103380 Cable gland ATEX M16 Black (RAL 9005) 1 pc(s)
4 mm
9 mm
M16
Minimum order quantity: 1
Multiple: 1
€ 5.87*
Wiska 10103382 Cable gland ATEX M25 Black (RAL 9005) 1 pc(s)
10 mm
17 mm
M25
Minimum order quantity: 1
Multiple: 1
€ 6.71*
Documents & Downloads
Datasheet
Datasheet 530448 Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 530448 Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
Conformity certificate
Conformity certificate 530448 Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
Certificate
Certificate 530448 Wiska 10103381 Cable gland ATEX M20 Black (RAL 9005) 1 pc(s)
Description
Explosion-proof cable gland with connecting thread sealing ring for optimal sealing. Strain relief using patented lamellar system. Additional measures are taken here in order to exclude (with a higher degree of safety) the possibility of impermissibly high temperatures and the formation of sparks and electric arcs inside or on external parts of electrical equipment, where these do not occur during normal operation.
Scope of delivery
- Incl. connecting thread sealing ring.
Hints
Increased safety to EN 50 019.
