Image similar
Image similar
Phoenix Contact Socket housing cable QC Total number of pins 2 Contact spacing: 5 mm 1921670 50 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
QC
CS
5 mm
Datasheet (PDF)
1 Set(s)
Sales and shipping:
Number (Package size 50 pc(s))
Total (€ 1.41 / piece)
€
Only 1 Set(s) available
Highlights & Details
Printed-circuit board connector QC 1/ 2-ST-BUS
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 2
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
QC
- Features
+ IDC
- CS
5 mm
- Pins per row
2
- Total number of pins
2
- Width
28.20 mm
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Content
50 pc(s)
- AWG max.
18
- AWG (min.)
20
- Dim
(L x W x H) 10.90 x 28.20 x 15.00 mm
- Connection
Cut & Clip
- Manufacturer part #
1921670
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
630 V
- Height
15.00 mm
- Length
10.90 mm
- max. cross section
0 mm²
- Min. cross section
0.5 mm²
- RoHS-compliant
- Type
QC 1/ 2-ST-BUS
Documents & Downloads
Datasheet
Datasheet 774271 Phoenix Contact Socket housing cable QC Total number of pins 2 Contact spacing: 5 mm 1921670 50 pc(s)
User & Safety Instructions
User & Safety Instructions 774271 Phoenix Contact Socket housing cable QC Total number of pins 2 Contact spacing: 5 mm 1921670 50 pc(s)
Description
Plug component, Nominal current: 10 A, Rated voltage (III/2): 630 V, Number of positions: 2, Pitch: 5 mm, Connection method: Insulation displacement connection QUICKON, Color: green, Contact surface: Tin, The plug allows conductors to be looped through from module to module, without interruption
