Siemens 5SV36446 5SV3644-6 RCCB A 4-pin 40 A 0.3 A 400 V
EAN:
Part number:
Item no:
Nominal current - rounded value
40 A
Differential current rating
0.3 A
Number of pins
4
Release characteristics
A
Product type
RCCB
Datasheet (PDF)
2 Piece(s)
Sales and shipping:
Number
Total (€ 53.77 / piece)
€
Only 2 Piece(s) available
Technical specifications
- Mechanical life (Cycles): 10000
- IP20, for distributor installation, with the connected conductors
- Nominal current
40 A
- Nominal current - rounded value
40 A
- Content
1 pc(s)
- Dim
(W x H x D) 72 x 90 x 70 mm
- Factory colour
Grey
- Depth
70 mm
- Height
90 mm
- Width
72 mm
- Differential current rating
0.3 A
- Type
Design of the product: without delay; Mounting Type: DIN rail
- Nominal voltage
400 V
- Switch-off capacity
0.8 kA
- Number of pins
4
- Release characteristics
A
- RoHS-compliant
Yes
- Weight
0
DIN rail
AC
70 mm
40 A
400 V
2000 V
4
0.3 A
A
FALSE
10 kA
1 kA
2
4
FALSE
7035
FALSE
2 W
50 Hz
IP20
0.75-35 mm²
0.75-35 mm²
TRUE
-25-45 °C
TRUE
6
- Product type
RCCB
Documents & Downloads
Datasheet
Datasheet 1418961 Siemens 5SV36446 5SV3644-6 RCCB A 4-pin 40 A 0.3 A 400 V
User & Safety Instructions
User & Safety Instructions 1418961 Siemens 5SV36446 5SV3644-6 RCCB A 4-pin 40 A 0.3 A 400 V
Description
GROUND fault circuit breaker, 4-pole, type A, in: 40 A, 300 mA, UN AC: 400 V of the FI switch is the residual current protection device for touch protection The patented residual current protection devices from Siemens are an important component of the SENTRON protective components for electrical installation, because they prevent life-threatening electric shocks by safely switching off dangerous fault currents against earth. Electrically ignited fires can be prevented even in the . Whether by direct contact with live parts during operation or by indirect contact with equipment, the protection is achieved primarily by rapid shutdown. The Siemens 5SV FI circuit breakers are characterized above all by: 1. Comprehensive protection for persons and property against electric shock. 2. Whether sinusoidal AC fault currents or smooth DC fault currents, Siemens offers the right type and special versions for all requirements. 3. Reliable safety during installation thanks to the standard included comprehensive and touch protection. 4. Tool-free release from the DIN rail or from the busbar network by means of convenient slide-manual operation. 5. Datamatrix code on the front of the device offers all information about the FI-circuit breaker quickly and easily. 6. Be protected according to standards: The residual current circuit breakers comply with the DIN VDE regulations. 7. Optimum technology for your safety - only from Siemens.
