TracoPower DC/DC converter (print) 12 V DC 12 V DC 1.3 A 15 W No. of outputs: 1 x Content 10 pc(s)
EAN:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Total (€ 37.40 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 15-1212
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
1.3 A
- Output current (max.) - rounded
1.3 A
- Efficiency (max.)
86 %
15 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
15 g
- Content
10 pc(s)
Documents & Downloads
Datasheet
Datasheet 2791833 TracoPower DC/DC converter (print) 12 V DC 12 V DC 1.3 A 15 W No. of outputs: 1 x Content 10 pc(s)
Datasheet 2791833 TracoPower DC/DC converter (print) 12 V DC 12 V DC 1.3 A 15 W No. of outputs: 1 x Content 10 pc(s)
User & Safety Instructions
User & Safety Instructions 2791833 TracoPower DC/DC converter (print) 12 V DC 12 V DC 1.3 A 15 W No. of outputs: 1 x Content 10 pc(s)
Warranty Terms
Warranty Terms 2791833 TracoPower DC/DC converter (print) 12 V DC 12 V DC 1.3 A 15 W No. of outputs: 1 x Content 10 pc(s)
Description
Ultra-compact dimensions: 25.4 mm x 25.4 mm x 10.2 mm, 2:1 input range, input/output insulation 1500 V/DC, external on/off, industry standard footprint.
