WAGO 741-132 Spring-loaded terminal 2.50 mm² Number of pins 2 Grey 180 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number (Package size 180 pc(s))
Total (€ 293.28 / piece)
€
Technical specifications
- GDS-DURCHFüHRUNGSL.M.BF 2-POL.RM5
- Features
+ CAGE CLAMP®
- CS
5 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
741
- Min. stripping length
5 mm
- Stripping length (max.)
6 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
16 A
- Cross section (flexible) (min.)
0.08 mm²
- Nominal current - rounded value
16 A
- Cross section (inflexible) (min.)
0.08 mm²
- Cross section (flexible) (max.)
2.50 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
28
- Connector orientation
Parallel (to the PCB)
- AWG max.
12
- Contact material
Cathode copper, tin plated
- Enclosure material
Polyamide
- Factory colour
Grey
- Wire protection
Yes
- Actuation direction
Parallel (to the PCB)
- Content
180 pc(s)
- Height
19.40 mm
- Length
12.80 mm
- Width
22.50 mm
- Industrial packaging
Yes
- Manufacturer part #
741-132
- Type
741-132
- Nominal voltage
320 V
- Product type
Spring-loaded terminal
