ABB 1SBV013772R1211 LS35M72B11 Door-operated switch 10 A Tappet IP66 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Packaging type
Piece
- Product type
Door-operated switch
- Connection
Connector
- Operation type
Tappet
- Switching current (max.)
10 A
- Contact type
1 maker
1 breaker
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP66
- Material
Metal (powder-finished)
- Width
30 mm
- Type
LS35M72B11
- Content
1 pc(s)
- Dim
(L x W x H) 42 x 30 x 170 mm
- Height
170 mm
- Length
42 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3783198 ABB 1SBV013772R1211 LS35M72B11 Door-operated switch 10 A Tappet IP66 1 pc(s)
Information
Information 3783198 ABB 1SBV013772R1211 LS35M72B11 Door-operated switch 10 A Tappet IP66 1 pc(s)
Description
LS35M71B11 is a 30 mm wide position switch made of a zinc alloy (Zamak), with 2 mounting holes at the top, 1 1/2 inch NPT cable entry at the bottom, 1 flattened glass fiber rod pivot levers (adjustable) and 1 NO + 1 NC contact as a spring contact: LS30 - Standard
