ABB 1SVR340567R1000 Rail mounted PSU (DIN) 24 V 7.5 A 120 W Content 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Type
Output voltage regulated
- Type
short circuit resistant
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
3 V AC
- Input voltage
3 V/AC - 575 V AC
- Input voltage (max.)
575 V AC
- Max. output current
7.5 A
- Output current (max.) - rounded
7.5 A
120 W
- Output voltage (nominal)
24 V
- Dim
(L x W x H) 126.8 x 35.5 x 129.4 mm
- Manufacturer part #
1SVR340567R1000
- Content
1 pc(s)
- PSU features
Regulated
- Width
35.5 mm
- Height
129.4 mm
- Length
126.8 mm
- Type
CP-S.3 24/5.0
- Efficiency
94 %
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3783727 ABB 1SVR340567R1000 Rail mounted PSU (DIN) 24 V 7.5 A 120 W Content 1 pc(s)
Description
CP-S.3-power supplies: High efficiency and reliability in compact design. The series was developed for numerous applications, including mechanical engineering. The series has an integrated power reserve of 150% for five seconds and works with an efficiency of up to 94%. The new CP-S.3 power supplies provide overheating protection and active power factor correction, a wide certified AC and DC input range and comprehensive worldwide approvals, including marine. They are the preferred choice for a variety of industrial applications.
