ABB 1SVR427041R0000 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 48.73 / piece)
€ 48.73
plus VAT.
14-day return policy included
Highlights & Details
ABB power supply for distribution cabinet installation CP-D 24/1.42
- Input voltage 100 - 240 V
- Output voltage 24 V
- Output current: 0.42 A
- Output power max. 10 W
Technical specifications
- Nominal input voltage
AC 100-240V
- Product type
Rail mounted PSU (DIN)
- Max. output current
0.42 A
- Output current (max.) - rounded
420 mA
10 W
- Output type (power supply units)
Fixed voltage
- Output voltage (nominal)
24 V DC
- Dim
(W x H x D) 18 x 91 x 57.5 mm
- Weight
0
- Manufacturer part #
1SVR427041R0000
- Content
1 pc(s)
- Width
18 mm
- Height
91 mm
- Type
CP-D 24/0.42
- Depth
57.5 mm
- Max. nominal current
0.42 A
- Output voltages
24 V
- Operating voltage
240 V
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1826899 ABB 1SVR427041R0000 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1826899 ABB 1SVR427041R0000 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W Content 1 pc(s)
Conformity certificate
Conformity certificate 1826899 ABB 1SVR427041R0000 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W Content 1 pc(s)
Description
The modular power supplies in mdrc design of the series CP-D (modular DIN-rail components) can optimally in distributor must be installed. This series includes devices with output voltages of 12V DC and 24 V DC at an output current of 0.42 A up to 4.2 A. Thanks to the high thermal efficiency and the related low power loss and low heat build-up in the devices can be operated without forced cooling. All devices have a U/I-output characteristic (fold-forward behavior). The power supplies of the series CP-D are in accordance with all applicable international standards.
