ABB 2CSF204101R2400 F204 A-40/0,1 RCCB A 4-pin 40 A 0.1 A 400 V
EAN:
Part number:
Item no:
Product type
RCCB
Number of pins
4
Release characteristics
A
Differential current rating
0.1 A
Nominal current - rounded value
40 A
Datasheet (PDF)
Technical specifications
- Product type
RCCB
- Number of pins
4
- Release characteristics
A
- Differential current rating
0.1 A
- Nominal current
40 A
- Nominal current - rounded value
40 A
- Content
1 pc(s)
- Nominal voltage
400 V
- Depth
69 mm
DIN rail
AC
69 mm
40 A
400 V
500 V
4
0.1 A
2
4
FALSE
IP2X
25-25 mm²
25-25 mm²
-25-55 °C
TRUE
4
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2321179 ABB 2CSF204101R2400 F204 A-40/0,1 RCCB A 4-pin 40 A 0.1 A 400 V
User & Safety Instructions
User & Safety Instructions 2321179 ABB 2CSF204101R2400 F204 A-40/0,1 RCCB A 4-pin 40 A 0.1 A 400 V
Description
Residual current protective devices (RCCBs) offer personal and property protection as well as protection against electrically ignited fires in accordance with DIN VDE 0100-410 and DIN VDE 0100-530. The F200 series residual current circuit breakers provide protection for sinusoidal alternating currents and pulsating currents with smooth DC residual current of up to 6 mA against earth. As well as fault protection (protection against indirect contact), additional protection (with IΔn ≤ 30 mA) and fire protection (with IΔn ≤ 300 mA). They meet the product standards IEC/EN 61008-1, 61008-2-1, 61543 (VDE 0664 10, 11, 30) and for F200 A to 100 A UL 1053. Applications include domestic, commercial and industrial applications. The extensive range of accessories offers you everything was needed for your installation tasks. Numerous approvals make the F200 fit for worldwide use.
