ABB 2CSM200893R1801 E 91N/32 Fuse disconnect switch Suitable for Micro fuse 10.3 x 38 mm 690 V 1 pc(s)
EAN:
Part number:
Item no:
Product type
Fuse disconnect switch
Nominal voltage
690 V
Suitable for
Micro fuse 10.3 x 38 mm
Material
Thermoplastic
IP rating
IP20
Datasheet (PDF)
Technical specifications
- Product type
Fuse disconnect switch
- Nominal voltage
690 V
- Material
Thermoplastic
IP20
- Suitable for
Micro fuse 10.3 x 38 mm
- Number of fuses
2
- Content
1 pc(s)
- Type
E 91N/32
690 V
DIN rail
TRUE
64 mm
2
2
IP20
TRUE
400 V
FALSE
10x38 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3112468 ABB 2CSM200893R1801 E 91N/32 Fuse disconnect switch Suitable for Micro fuse 10.3 x 38 mm 690 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3112468 ABB 2CSM200893R1801 E 91N/32 Fuse disconnect switch Suitable for Micro fuse 10.3 x 38 mm 690 V 1 pc(s)
Description
Fuse disconnect switch for 10.3 x 38 mm fuses for switching under load and protection against short circuit and overload. Housing made of self-extinguishing thermoplastic with high temperature resistance and contact clamps made of silver-plated copper. E 90 Fuse disconnect switches can be sealed (closed) or closed (open). Compatible with phase rails of the S 200-series.
