ABB 2CSM289613R1801 E 93/20S Fuse disconnect switch incl. status indicator 400 V 1 pc(s)
EAN:
Part number:
Item no:
Product type
Fuse disconnect switch
Nominal voltage
400 V
Features
incl. status indicator
Material
Thermoplastic
IP rating
IP20
Datasheet (PDF)
Technical specifications
- Product type
Fuse disconnect switch
- Features
incl. status indicator
- Nominal voltage
400 V
- Material
Thermoplastic
IP20
- Number of fuses
3
- Length
31.5 mm
- (Ø)
8.5 mm
- Content
1 pc(s)
- Dim
(Ø x L) 8.5 mm x 31.5 mm
- Type
E 93/20S
400 V
DIN rail
TRUE
64 mm
3
3
IP20
TRUE
TRUE
8.5x31.5 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3112627 ABB 2CSM289613R1801 E 93/20S Fuse disconnect switch incl. status indicator 400 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3112627 ABB 2CSM289613R1801 E 93/20S Fuse disconnect switch incl. status indicator 400 V 1 pc(s)
Description
Fuse disconnect switch for 8.5 x 31.5 mm fuses for switching under load and protection against short circuit and overload. Housing made of self-extinguishing thermoplastic with high temperature resistance and contact clamps made of silver-plated copper. E 90 Fuse disconnect switches can be sealed (closed) or closed (open). Compatible with phase rails of the S 200-series. With fuse breakage display.
This text is machine translated.
This text is machine translated.
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
