ABB 7TCA085400R0348 OVR 110E Surge arrester 10 kA 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product type
Surge arrester
- Leakage current
10 kA
- Nominal voltage
110 V AC
- Manufacturer part #
7TCA085400R0348
- Content
1 pc(s)
DIN rail (top hat rail) 35 mm
Other
45-45 MHz
2.5 kA
FALSE
45 MHz
FALSE
132 V
10 kA
1.25 A
36 V
36 V
None
36 V
36 V
110-110 V
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3120083 ABB 7TCA085400R0348 OVR 110E Surge arrester 10 kA 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3120083 ABB 7TCA085400R0348 OVR 110E Surge arrester 10 kA 1 pc(s)
Description
Combined overvoltage protection, tested in category D, C, B (EN 61643), suitable for twisted double wires for signal transmission. For protecting resistance-sensitive systems with frequencies up to 45 MHz. Suitable for DC applications up to 1.25 A. Available for nominal voltages of 6, 15, 30, 50 and 110 volts. For use at limits of LPZ 0 to protect against rollover (typically at the location of the cable entry) up to LPZ 3 to protect sensitive electronic equipment.
