ABB AF09ZB-30-10RT-22 Contactor 3 makers 4 kW 9 A + surge protection Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Contactor
No. of pins
3-pin
Current load
9 A
Power
4 kW
Packaging type
Piece
Technical specifications
- Packaging type
Piece
- Product type
Contactor
- Type
AF09ZB-30-10RT-22
- No. of pins
3-pin
- Contact type
3 makers
- Auxiliary contact type
1 maker
- Control voltage (min.)
48 V AC
48 V DC
- Control voltage (max.)
130 V AC
130 V DC
- Control voltage range
48, 48 - 130, 130 V AC, V DC
- Switching voltage (min.)
690 V AC
- Switching voltage (max.)
690 V AC
- Permanent current (max.)
9 A
- Current load
9 A
4 kW
- Features
+ surge protection
- Width
45 mm
- Height
86 mm
- Depth
77 mm
- Dim
(W x H x D) 45 x 86 x 77 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3783333 ABB AF09ZB-30-10RT-22 Contactor 3 makers 4 kW 9 A + surge protection Piece 1 pc(s)
Description
The 3-pin AFZB contactors comply with the latest standards for rolling rail vehicles and allow installation in passenger or driver's cabs of trains that frequently operate in tunnels or underpasses. They switch power circuits with motors, slightly inductive or non-inductive loads. They meet all the important standards for rolling stock: IEC 60947-4-1, IEC 60947-5-1, IEC 60077-1/-2 and applicable parts of standards EN 50155, shock and vibration resistance in accordance with IEC 61373 Cat 1, Class B. They also achieve the highest levels of fire and smoke performance in compliance with European standard EN 45545-2 (HL2 risk levels) for group installation. The AFZB contactors can withstand short voltage drops and voltage drops (according to SEMI F47-0706). All integrated or subsequently mounted auxiliary NC contacts are designed as mirror contacts in accordance with IEC60947-5-1 Annex L. Furthermore, they have a built-in surge protector and do not require any additional quenching elements.
