ABB AF146-30-00-13 Switch 4 makers 100 V 225 A + auxiliary contact Piece 1 pc(s)

'A grey electrical switch by ABB with technical specifications on the front, suitable for industrial applications.'

'A grey electrical switch by ABB with technical specifications on the front, suitable for industrial applications.'

Product type

Switch

No. of pins

2-pin

Nominal voltage

100 V

Current load

225 A

Connection

Clamp

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Packaging type: Piece

Product type: Switch

Type: AF146-30-00-13

No. of pins: 2-pin

Contact type: 4 makers

Auxiliary contact type: 4 makers

Nominal voltage: 100 V

Switching voltage (max.): 75 V AC

Permanent current (max.): 225 A

Current load: 225 A

Features: + auxiliary contact

Connection: Clamp

Content: 1 pc(s)

: 90

: 150 mm

: 126 mm

: FALSE

: 75 kW

: 3

: 0

: 0

: 0

: 146 A

: 225 A

: 100-250 V

: 100-250 V

: 100-250 V

: Screw connection

: 1000-1000 V

: 1000-1000 V

: AC/DC

: 37.285

UKCA: yes
