ABB AFS12Z-30-22-30 Contactor 5 makers, 2 breakers 5.5 kW + surge protection 1 pc(s)
EAN:
Part number:
Item no:
Product type
Contactor
No. of pins
3-pin
Power
5.5 kW
Connection
Screws
Type
AFS12Z-30-22-30
Datasheet (PDF)
Technical specifications
- Product type
Contactor
- Type
AFS12Z-30-22-30
- No. of pins
3-pin
- Contact type
5 makers
2 breakers
- Control voltage (min.)
24 V DC
- Control voltage (max.)
24 V DC
- Control voltage range
24 - 24 V DC
- Permanent current (max.)
28 A
5.5 kW
- Features
+ surge protection
- Connection
Screws
- Content
1 pc(s)
FALSE
5.5 kW
3
0
2
2
12 A
28 A
24-24 V
Screw connection
DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3105234 ABB AFS12Z-30-22-30 Contactor 5 makers, 2 breakers 5.5 kW + surge protection 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3105234 ABB AFS12Z-30-22-30 Contactor 5 makers, 2 breakers 5.5 kW + surge protection 1 pc(s)
Description
The 3-pole contactors AFS..Z are designed for applications in machine safety. They are supplied with fixed color-coded auxiliary contact blocks on the front and are therefore suitable Ideal for monitoring and controlling power circuits with motors, slightly inductive or non-inductive loads. The contactors enable direct control by ≥24V DC 250mA PLC outputs with a very low holding power of only 1.7W. The integrated auxiliary contacts are positively driven and are designed as mirror contacts in accordance with IEC60947-5-1 Annex L. Furthermore, they have a built-in surge protector and do not require any additional quenching elements. Minimum switching capacity of the auxiliary contacts 12V / 3mA, with a failure rate 10-7 in accordance with IEC 60947-5-4.
