ABB B24 111-100 2CMA100177R1000 Converter meter Digital 6 A MID-approved: Yes 1 pc(s)
EAN:
Part number:
Item no:
Product type
Converter meter
Current load
6 A
Display
Digital
Calibration
Calibrated
Dim
(L x W x H) 65 x 70 x 26.5 mm
Datasheet (PDF)
Technical specifications
- Product type
Converter meter
- Current load
6 A
- Display
Digital
- Calibration
Calibrated
- Dim
(L x W x H) 65 x 70 x 26.5 mm
- Weight
0
- Self-consumption
0.721 W
- Recess width
70 mm
- Accuracy class
B
- MID-approved
Yes
- Reading type
Active energy
- Width
70 mm
- Height
26.5 mm
- Length
65 mm
- Current (max.)
6 A
- Current range
6 A (max)
- Type
B24 111-100
- Effective current range
6 A
DRA (DIN-rail adapter)
70 mm
Measurement transformer
26.5 mm
65 mm
Purchase
Digital
6 A
4
7
Electronic
IP20
Other
Effective power
One-tariff
TRUE
TRUE
Measuring Instruments Directive
Electrical
S0
B
Four conductor
FALSE
FALSE
FALSE
6 A
Other
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3118746 ABB B24 111-100 2CMA100177R1000 Converter meter Digital 6 A MID-approved: Yes 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3118746 ABB B24 111-100 2CMA100177R1000 Converter meter Digital 6 A MID-approved: Yes 1 pc(s)
Description
Three-phase meter for measuring a three-phase or four-conductor three-phase current supply via a converter connection CT (converter ratio configurable for current) up to a maximum of 6 A. The following values are output via a seven-segment display with up to 7 digits: Active energy (class 1), power, currents, voltages (L-N) and frequency, per phase as well as total. Communication can take place via the infrared interface for connecting a KNX module. The energy meter has a pulse output. The meter is calibrated to MID and approved according to IEC. The installed width is 4 DIN modules.
