ABB CR-P230AC1 Interface relay Nominal voltage: 230 V Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Interface relay
Nominal voltage
230 V
Switching voltage (max.)
250 V DC/AC
Type
CR-P230AC1
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Interface relay
- Type
CR-P230AC1
- Connection
Jack connector
- Max. pick-up voltage
230 V AC
- Nominal voltage
230 V
- Switching voltage (max.)
250 V DC/AC
- Features
pluggable
IP67
- Width
12.7 mm
- Height
15.7 mm
- Dim
(W x H) 12.7 mm x 15.7 mm
- Content
1 pc(s)
With plug-in socket
12.7
29 mm
0
0
1
230-230 V
230-230 V
FALSE
AC
Documents & Downloads
Datasheet
Datasheet 3333716 ABB CR-P230AC1 Interface relay Nominal voltage: 230 V Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3333716 ABB CR-P230AC1 Interface relay Nominal voltage: 230 V Piece 1 pc(s)
Description
As an interface, interface relays connect the electronic control level, for example PLC, to the level of sensors/actuators. Here they take over various functions: Switching of direct or alternating current loads with different ohmic, inductive and capacitive proportions, switching in the voltage range from a few mV to 250 V, switching in the current strength range from a few mA to 16 A, amplification of weak control signals, potential separation of control and load circuits as well as signal multiplication. The CR-P series has 9 different coil voltages with 1-2 changeover contacts. Two socket versions are available: Standard socket and logical socket. Plug-in function modules such as reverse polarity protection / snubber diode, LED module, RC links, overvoltage protection or time modules add to the range of applications on pluggable PCB relays.
